Unveiling the Mysteries of Print-Ready Documents

The printable PDFs are out there…you just have to believe in them!

in printable PDFs.png — Original image by Brittni DeWeese

Ok ok, believing isn’t quite enough - you also have to get comfortable with PDF/X, the PDF file type based on the ISO standard that ensures that PDF files capture the right information needed to print correctly - with color and font accuracy - to the capabilities of the output device (aka printer).

Why adhere to PDF/X standards, you may ask? Well, only some PDFs are built for print, while others are built for online distribution on the web. The way your PDFs are built will determine how they are sent to you from your customers, and in turn how they are printed.

Some PDFs can also be malformed and have syntax issues, missing fonts, or color problems, which could screw up the printing process. If you aren’t sure if you have those issues, you can use Acrobat Preflight tools to see if the file is clean. Browsing the internal structure of the PDF and looking for errors can also help you determine if anything needs to be remedied before going to print. Completing a few other common pre-print actions will help you determine if your files are print-ready.

Common pre-Print actions you can take include:

Split & Merge – merge multiple PDF files together, or split them up as needed by page number
Color profile accuracy – make sure your color profiles match up with intended print output
Transparency flattening – flatten transparent objects into vector-based or rasterized objects
Color conversion – convert RGB to CMYK or spot colors as needed

PDF/X File Subsets and Requirements

PDF/X-1a

PDF/X-1a is a specific subset of PDF/X designed for ensuring the reliable and high-quality printing of graphic content. The "1a" in PDF/X-1a refers to the first version of the PDF/X standard. This standard is widely used in the graphic arts and printing industry to create print-ready PDF files with a focus on simplicity and reliability.

Key features and requirements of PDF/X-1a include:

Color Spaces: All color in the document must be defined in either CMYK or spot colors. RGB and other color spaces aren’t allowed.
Fonts: Fonts must be embedded in the document to ensure proper display and printing. Only Type 1 or TrueType fonts are allowed.
Transparency: Transparency is not supported in PDF/X-1a. Any transparent objects must be flattened.
Layers: Layers are not allowed in PDF/X-1a. The document must be a single, flat layer.

PDF/X-3

PDF/X-3 is another subset of the PDF/X standard, specifically designed for graphic arts and printing workflows. Like PDF/X-1a, PDF/X-3 creates a reliable format for the exchange of print-ready documents, but it offers some additional features compared to PDF/X-1a.

Key features and requirements of PDF/X-3 include:

Color Spaces: PDF/X-3 allows for a broader range of color spaces, including CMYK, RGB, and grayscale. This flexibility is beneficial for workflows that involve a mix of color spaces.
Transparency: Unlike PDF/X-1a, PDF/X-3 supports transparency. Transparency effects, such as drop shadows and blends, can be used in the document. Transparency must be flattened upon export to ensure reliable printing, however.
Layers: PDF/X-3 supports layers, making it more suitable for documents with complex layer structures. However, it's important to note that not all print workflows may fully support layers, so care must be taken in their use.

PDF/X-4

PDF/X-4, like PDF/X-1a and PDF/X-3, is another subset of the PDF/X standard and is similar to both, though supports quite a few things that PDF/X-1a does not, including device-independent color spaces, live PDF transparency, and layers.

PDF/X-4 moves a lot more of the responsibility downstream into the RIP, because it can carry unseparated colors and transparency.

PDF/X-6

PDF/X-6 (ISO1530-9) is the latest evolution of the PDF/X standard; it is a specific standard for the creation and exchange of print-ready PDF files in the graphic arts industry.. PDF/X-6 is based on the PDF 2.0 specification, which provides advanced features and enhancements compared to previous versions of PDF. It supports transparency, layers, OpenType fonts, and ICC color profiles, among other features.

There you have it - the PDF/X mystery is solved!

Now that you have a better understanding of PDF/X, go out there and create beautiful, printable PDFs that even Dana Scully won’t be skeptical of! Sign up for a free trial of ourAdobe PDF Library SDK today.
